Composite and Non-Destructive Testing Laboratory

In this laboratory, CAD software is used to increase the productivity of the designer, improve the quality of design, improve communications through documentation, and to create a database for manufacturing. The design softwares are capable to form technical drawings from a 2D drafting until 3D solid modelling. These CAD data can be linked with other third party machines such as FDM, 3D printer, and CNC machine in order to form a reality prototype.

0
Equipment

Equipment .

A heat press machine utilizes heat in order to apply designs onto various substrates. It uses a combination of pressure from the heated upper platen onto the lower platen in order to achieve its results.

Hsin-Chi Machinery – 200 Ton High Speed Hot Press Hydraulic Machine Model HL-200.

Hydraulic press uses hydraulic cylinder to generate a compressive force. The machine is used for forging, clinching, moulding, blanking, punching, deep drawing, and metal forming operations. Hydraulic presses are also used for stretch forming, rubber pad forming, and powder compacting.

DEESHA

Compression molding is a method of molding in which the molding material, generally preheated, is first placed in an open, heated mold cavity. Compression molding is a high-volume, high-pressure method suitable for molding complex, high-strength fiberglass reinforcements. Advanced composite thermoplastics can also be compression molded with unidirectional tapes, woven fabrics, randomly oriented fiber mat or chopped strand.

Gotech GT-7014-A30

Gallery .

Contact Us

To know more about this lab, or if you require a specific service to serve your needs.

Ts. Dr. Mohd Adrinata Shaharuzaman

Laboratory Coordinator

adrinata@utem.edu.my

+606 270 4411
